General Information
Product Family Vajra Series
Camera Model Vadzo Vajra-2020MRS
Sensor
Sensor AR2020 CMOS Sensor from Onsemi Hyperlux™ LP
Sensor Format 1/1.8"
Pixel Size 1.4 µm x 1.4 µm
Max Resolution 20MP - 5120(H) x 3840(V)
Shutter Rolling Shutter
Chroma Mono
Camera
Optics S Mount (M12 Standard)
Lens FOV 74 DFOV
Interface USB 3.2 Gen 2x2 Type C Interface Backward Compatible to USB 3.2 Gen 1
GPIO Connector Yes Available*
Power USB Powered
Operating Temperature -30⁰C to 70⁰C
Dimension 38mm (L) x 38mm (B) convertible to 32mm (L) x 32mm (B)
Weight 18 Grams (Without Lens)
OS Supported Windows and Linux.
Conformity UVC Compliant, RoHS 3, REACH
AR2020 Monochrome 20MP USB 3.2 Gen 2x2 Camera
Vajra-2020MRS
Series :
Vajra-2020MRS
Description :
Vadzo Vajra-2020MRS is a 20MP USB 3.2 Gen 2x2 UVC Camera based on Onsemi Hyperlux™ LP AR2020 Imaging Sensor. The camera comes with inherent capabilities such as enhanced dynamic range (eDR), excellent Low-Light and NIR Sensitivity. The camera delivers max resolution of 20MP and Video streaming of 4K, 1080p and 720p. Applicable in use cases such as Machine Vision Applications, Digital Pathology, Quality Inspection, Biometrics, Etc.
OUT OF STOCK
(Will be available in 8 weeks)
Mentioned Price is Applicable for orders above 1k unit
The shipment will be delivered in 3 to 4 weeks.
Price Details
UNIT PRICE
NOT INCLUSIVE
Contact Sales
Lens & Cable
QUANTITY
1 - 249
1000 - 4999
Contact Sales
Contact Sales
Lens & Cable
Lens & Cable
250 - 999
Login to Download Datasheet
Datasheet
Download Initiated!
You can download again after 60 seconds.
CAD File
Download Initiated!
You can download again after 60 seconds.
Downloads
Vajra-2020MRS
Camera can be customized to meet your needs.
Vadzo team shall be able to assist you with the details on this. Reach Vadzo Team for customization & quotation for bulk quantities.
Form Factor Modification & Board Redesigns.
Firmware Modifications to Incorporate Custom Features.
Design & Integration of NIR and Color LED Array Boards.
Design & Integration of Microphones & Speakers.
Design & Integration of Advanced Sensors: ToF, mmWave Radar, IMU.
Lens Holder Modifications & Electro-Mechanical Lens Filter Control.
Enclosure Design & Manufacturing: IP-Rated and Non IP-Rated.
